A collection of cutaways of AK-47, Colt .45, tanks, Russian nuclear submarines, rocket launchers, grenades... a fascinating look into the guts of 12 iconic weapons.

Yankee 667M Andromeda: Russian submarine equipped with nuclear missiles.

9k113 Konkurse: Russian anti-tank missile.

RPG-18: Russian short-range, disposable light anti-tank rocket launcher.

Rheinmetall 35mm Oerlikon AHEAD airburst ammunition.

British WWI 18-pounder shrapnel shell.

Mauser C96

Colt 45.

DM1 grenade.

Leopard I tank.

M16.

Ak 47.

Spanish Cetme: Licensed by the German weapon industry.
